◎测量范围:0.5MPa～200MPa
◎外形小，适合空间有限的场合
◎用途：测量粘稠液体，易结晶液体等
规格参数/Specifications
| 额定量程/Rated capacity | 0.5,1,1.6,2,3,5,10,20,60,200 MPa | |||||||
| 额定输出/Rated output | 0.5～4.5V,0～5V,0～10V,4～20mA | |||||||
| 精度/Accuracy | ±0.2, ±0.5%FS | |||||||
| 工作电压/Power supply voltage | DC24V(12～30V) | |||||||
| 工作温度范围/Temp. range, safe | -20～85℃ | |||||||
| 补偿温度范围/Temp. range, compensated | -10～80℃ | |||||||
| 安全荷载/Safe overload | 150%FS | |||||||
| 防护等级/Class of protection | IP65 | |||||||
| 安装螺纹/Mounting screw | M20*1.5 | |||||||
| 测量介质/Measure media | 水、气体和油/Water, gas and oil | |||||||
| 电缆长度/ Cable length | 0m | |||||||
| 材质/Material of pressure hole | 304不锈钢/stainless steel(304) | |||||||
| 质量/Weight | 约150g | |||||||
